Description
The Portable Conductivity/DO Meter YR06382 is an advanced measurement tool ideal for laboratory and field applications. Its large LCD screen with controllable white backlight ensures clarity in diverse lighting conditions. With its built-in microprocessor, it offers intelligent functions like auto calibration, automatic temperature compensation (ATC), data storage, and automatic power-off, making it an efficient and reliable solution for measuring conductivity, TDS, salinity, resistivity, and dissolved oxygen (DO).
Market Price
The average market price for advanced conductivity and DO meters like the Portable Conductivity/DO Meter YR06382 ranges between $700 and $1200. This price range reflects the quality and precision of the device, positioning it as a valuable investment for professionals requiring accurate and reliable measurement tools.
Frequently Asked Questions
Q: How often does the device need calibration?
A: The YR06382 features auto calibration, but it’s recommended to verify calibration regularly for optimal accuracy.
Q: Can this meter store multiple readings?
A: Yes, it can store up to 200 sets of data.
Advantages and Disadvantages
Advantages: The meter offers high accuracy (±1.0% FS), various measurement modes, and is IP57 rated for dust and water resistance.
Disadvantages: The device uses AA batteries, which may require frequent replacement depending on usage.
Field Usage
The Portable Conductivity/DO Meter YR06382 is essential for environmental monitoring, water quality assessment, and educational purposes. Its portability and robust construction make it suitable for on-site testing, ensuring precise data collection in real-world conditions.
Recommendations
For optimal performance, it is advisable to regularly check the electrode condition and replace it as needed. Using the device within its specified temperature range (5 ~ 35 ºC) will also help maintain accuracy.
Features
- Advanced conductivity measurement technology.
- Switch between conductivity, TDS, salinity, and resistivity modes.
- Auto calibration and compensation for temperature, salinity, and pressure.
- Polarographic DO electrode with short polarization time.
- IP57 dustproof and waterproof rating.
Technical Specifications
| Model | YR06382 | |
| Cond. | Measuring range | Conductivity: |
| (0.00~19.99)μS/cm | ||
| (20.0~199.9)μS/cm | ||
| (200~1999)S/cm | ||
| (2.00~19.99)mS/cm | ||
| (20.0~199.9)mS/cm | ||
| TDS:(0~100)g/L | ||
| Salinity:(0~100)ppt | ||
| Resistivity:(0~100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS, Overall:±1.5% FS | |
| Temp. compensation | (0~100)ºC(Auto/manual) | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
| DO | Measuring range | (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp. compensation | (0 ~ 45)ºC (auto) | |
| Salinity compensation | (0 ~ 45) ppt (auto) | |
| Pressure compensation | (66 ~ 200) kPa (manual) | |
| Auto calibration | Air saturated by water, water saturated by air | |
| Electrode type | Polarographic | |
| Temp. | Measuring range | (0 ~ 100)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
| Other | Data storage | 200 sets |
| Power | Two AA batteries (1.5V x2) | |
| Ambient Temp. | 5 ~ 35 ºC | |
| Ambient humidity | ≤85% | |
| IP grade | IP57 Dustproof and waterproof | |
| Dimensions/N.W. | (65×120×31)mm/180g | |
| Shipping size/G.W. | (460×300×55)mm/1Kg | |
