Description
The Multi-parameter Patient Monitor YR02177 is a state-of-the-art monitoring device designed for critical environments such as Operating Theaters (OT) and Intensive Care Units (ICU). With its 17-inch LCD screen and full modular parameter capabilities, it provides precise and real-time tracking of vital signs. Standard parameters such as ECG, SPO2, TEMP, NIBP, RESP, PR/HR ensure comprehensive monitoring, while optional configurations offer even more versatility. Whether you need advanced features like Masimo/Nellcor SpO2 or a thermal recorder, the YR02177 can be customized to meet the specific demands of patient care.
Market Price
Typically, multi-parameter patient monitors like the YR02177 are priced competitively in the medical equipment market. While prices can vary depending on the features and supplier, you can expect a range between $4000 and $5300 USD. This competitive pricing reflects the high functionality and adaptability of the monitor, making it a valuable investment for healthcare facilities.
Frequently Asked Questions
What environments is the YR02177 suitable for? The YR02177 is ideal for use in operating rooms and ICUs due to its comprehensive monitoring capabilities and robust design.
Can this monitor be wall-mounted? Yes, the YR02177 can be easily mounted on a wall, offering flexibility in crowded or space-limited environments.
Advantages and Disadvantages
The YR02177 offers numerous advantages, such as its modular design, which allows customization according to specific medical requirements. Its large screen and real-time data display enable easy monitoring. However, a potential downside might be the initial learning curve for healthcare professionals unfamiliar with modular systems.
Product Use in the Field
In practice, the YR02177 is employed in various critical care settings where precise monitoring is essential. It allows clinicians to track multiple vital signs simultaneously, which is crucial in making timely and accurate decisions for patient care.
Recommendations
To maximize the functionality of the YR02177, it is recommended to regularly update its software to the latest version. Additionally, periodic calibration and maintenance will ensure its accuracy and longevity. Utilizing the YR02177 alongside Kalstein Plus for automated quotations can streamline equipment acquisition and management processes.
Features
- 17-inch LCD screen for clear visualization
- Standard parameters: ECG, SPO2, TEMP, NIBP, RESP, PR/HR
- Customizable with optional modules
- Adaptable for wall mounting or mobile usage
- Advanced alarm systems for critical monitoring
Technical Specifications
| Model | YR02177 | |
|
ECG
|
Lead mode | 5 Leads(RA,LA,LL,RL,V) |
| Connection method | I, II, III,AVR,AVL,AVF,V | |
| Lead Mode | 3 Leads (RA,LA,LL) | |
| Connection method | I, II,III | |
| Waveform | 1ch | |
| Gain | x250, x500, x1000, x2000 | |
| HR Range | Adult: 15~300bpm | |
| Neo/Ped | 15~350bpm | |
| Accuracy | ±1% or ±1bpm | |
| Resolution | 1bpm | |
| Sensitivity | >200(uVp-p) | |
| Differential input impedance | ≥5MΩ | |
| ST segment Monitoring Range | ||
| Measure Range | -2.0~+2.0mV | |
| Measure Accuracy | -0.8mV~+0.8mV | |
|
Heart Rate
|
Measuring range | 10~300bpm |
| Accuracy | ±1bpm | |
| Resolution | 1bpm | |
| Sensitivity | >200UVp-p | |
|
Respiration
|
Method | Impedance between R-F(RA-LL) |
| Differential Input Impedance | >2.0MΩ | |
| Measuring Impedance Range | 0.3~3.0 MΩ | |
| Base line Impedance Range | 200~4000Ω | |
| Bandwidth | 0.1~2.5Hz | |
| Respiration Rate | Adult: 2~120BrPM | |
| Neo/Ped | 0~150BrPM | |
| Resolution | 1 BrPM | |
| Accuracy | ±2 BrPM | |
| Alarm | 10~40S | |
|
NIBP
|
Method | Oscillometric |
| Mode | Manual/Auto/STAT | |
| Measuring Interval in AUTO Mode | 1,2,3,4,5,10,15,30,60,90,120,180,240,480(Min) | |
| Measuring Period in STAT Mode | 5 Min | |
| Pulse Rate Range | 40~240bpm | |
| Alarm Type | SYS, DIA, MEAN | |
| Resolution | ||
| Pressure | 1mmHg | |
| Accuracy | Maximum Mean error: 5mmHg | |
| Maximum Standard deviation | 8mmHg | |
|
SPO2
|
Display | Number of SPO2,waveform of capacity,Pulse |
| Measuring range | 0~100% | |
| Resolution | 1% | |
| Accuracy | 70~100% (±2%) | |
| Alarm system | Audio-video alarm | |
| Pulse rate range | 0~300bpm | |
|
TEMP
|
Channel | 2 |
| Measuring and Alarm Range | 0~50ºC | |
| Resolution | 0.1ºC | |
| Accuracy | 0.1ºC | |
| Actualization interval | about 1 Second. | |
| Average Time Constant | <10 Second. | |
