Description
The Laboratory Microscope YR0237 is a top-tier choice for professionals seeking precision and reliability in laboratory settings. Featuring a Seidentopf binocular head inclined at 30° and an interpupillary distance range of 52-75mm, this microscope ensures comfortable and prolonged use during intricate examination of biological specimens. The inclusion of infinity semi-plan achromatic objectives (4x, 10x, 40x, 100x) guarantees enhanced clarity and contrast for observing fine details. Equipped with a sliding-in center adjustable condenser (N.A 1.25) and S-LED illumination with adjustable brightness, the YR0237 provides optimal light management for diverse analytical tasks in medical and scientific research.
Market Price Range
The Laboratory Microscope YR0237 typically falls within the price range of $1100 to $1900 in the market. While this may seem like an investment, the advanced features and robust build quality justify the cost for anyone who requires precise and detailed microscopic analysis.
Frequently Asked Questions
What is the difference between binocular and trinocular heads? A binocular head provides two eyepieces for viewing, while a trinocular has an additional port for connecting a camera for image capturing.
Can I use this microscope for fluorescence microscopy? Yes, optional EPI-Fluorescent Kits are available, which can be easily integrated with this model.
Is the magnification adjustable? Yes, with objectives ranging from 4x to 100x, users can achieve a broad range of magnifications.
Advantages and Disadvantages
Advantages: The YR0237 boasts high-quality optical components, ergonomic design, and comprehensive light control. It’s suitable for extensive laboratory applications due to its adaptability and precision.
Disadvantages: The initial cost may be high for entry-level users, and the advanced features could be more than what is necessary for basic educational settings.
Field Usage
In practical scenarios, the Laboratory Microscope YR0237 is ideal for use in clinical diagnostics, research laboratories, and higher education settings where detailed analysis of computer-generated visuals is critical. Its adaptability makes it a preferred choice for analyzing slides and samples in biological research.
Recommendations
To keep the microscope in optimal condition, we recommend regular maintenance, using dust covers when not in use, and avoiding abrasive cleaners on optical components. For those interested in extended imaging capabilities, consider pairing the device with compatible camera attachments or fluorescent kits available through Kalstein Plus.
Features
- Seidentopf Binocular/Trinocular Head
- Infinity Semi-Plan Achromatic Objectives
- Adjustable Condenser N.A 1.25
- Coaxial Coarse & Fine Adjustment
- S-LED Illumination, Adjustable Brightness
- Backward Quadruple Nosepiece
- Double Layer Mechanical Stage
Technical Specifications
| Model | YR0237 | YR0237-1 | |
| Head | Seidentopf Binocular Head, Inclined at 30°, Interpupillary Distance 52-75mm,Eyepiece Tubes Rotated 180° Up & Down | o | |
| Seidentopf Trinocular Head, Inclined at 30°, Interpupillary Distance 52-75mm,Eyepiece Tubes Rotated 180° Up & Down | o | ||
| Eyepiece | Wide Field Eyepiece WF10x/18mm | ||
| Objective | Infinite Semi-Plan Achromatic Objective 4x,10x,40x,100x | ||
| Nosepiece | Backward Quadruple Nosepiece | ||
| Stage | Double Layer Mechanical Stage, Size 140×140mm, Moving Range 75×50mm | ||
| Condenser | Sliding-in Center Adjustable Condenser N.A.1.25 | ||
| Focusing | Coaxial Coarse & Fine Adjustment, Moving Range 20mm | ||
| Illumination | S-LED Illumination, Adjustable Brightness | ||
| Laboratory Biological Microscope Optional Accessories | |||
| Eyepiece | WF10x/20mm, Diopter Adjustable | YR0237-1-op1 | |
| Objective | Infinity Plan Achromatic Objective 4x | YR0237-1-op2 | |
| Infinity Plan Achromatic Objective 10x | YR0237-1-op3 | ||
| Infinity Plan Achromatic Objective 40x | YR0237-1-op4 | ||
| Infinity Plan Achromatic Objective 100x | YR0237-1-op5 | ||
| Illumination | 6V20W Halogen Lamp, Brightness Adjustable | YR0237-1-op6 | |
| Dark Field | Dark Field Condenser, Dry, N.A.0.7~0.9 | YR0237-1-op7 | |
| Dark Field Condenser,Immersion, N.A.1.25~1.36 | YR0237-1-op8 | ||
| Dark Field Objective, Infinity Plan 100X, | YR0237-1-op9 | ||
| ForImmersion Dark Field Observation | |||
| Dark Field Objective, Infinity Plan 100X, With Iris Diaphragm | YR0237-1-op10 | ||
| ForImmersion Dark Field Observation | |||
| Phase Contrast | Infinity Plan Turret Phase Contrast Set | YR0237-1-op11 | |
| –Infinity Plan Turret Phase Contrast Condenser | |||
| –Ininity Plan Phase Contrast Objective 4x,10x,40x,100x | |||
| –Centering Telescope 10x | |||
| Infinity Achromatic Turret Phase Contrast Set | YR0237-1-op12 | ||
| –Infinity Achromatic Turret Phase Contrast Condenser | |||
| –IninityAchromatic Phase Contrast Objective 4x,10x,40x,100x | |||
| –Centering Telescope 10x | |||
| LED EPI-Fluorescent Kit | EPI Light 3W LED 465~475nm, B Excite Filter BP460~490 | YR0237-1-op13 | |
| EPI Light 3W LED 525~530nm, G Excite Filter BP510~550 | YR0237-1-op14 | ||
