Description
The Doppler Fetal Monitor YR02180 is an advanced medical device designed to monitor fetal heart rates and other vital parameters with high precision. Featuring a 17-inch LCD screen, this semi-modular monitor is suitable for both Operating Theatres and Intensive Care Units, offering six standard parameters: ECG, SPO2, TEMP, NIBP, RESP, and PR/HR. Its robust configuration, complemented by options for a touch screen, enhanced SpO2 technology, and additional leads, makes it a versatile tool for healthcare professionals.
Market Price
The average market price for a high-quality fetal monitor like the Doppler Fetal Monitor YR02180 generally ranges between $3,000 and $4,200 USD. This range reflects its state-of-the-art technology and adaptability in professional medical environments. To get an exact quote tailored to your needs, we invite you to request a quotation through the Kalstein Plus platform.
Frequently Asked Questions
How does the Doppler Fetal Monitor YR02180 ensure accurate readings? The monitor utilizes advanced signal processing and high sensitivity to deliver precise measurements.
Is the screen interface user-friendly? Yes, the 17-inch LCD screen offers a clear and intuitive interface, ensuring ease of use.
Advantages and Disadvantages
Advantages: Versatility in parameter monitoring, high-resolution display, and modular options for customization make it an excellent investment. Its reliability in providing accurate readings is unparalleled.
Disadvantages: Initial setup can be complex, requiring familiarization with its multiple functions and configurations.
Product Usage in the Field
In clinical settings, the Doppler Fetal Monitor YR02180 is employed extensively for continuous monitoring of fetal heart rates and maternal vitals, ensuring optimal patient care. Its adaptability to high-pressure environments makes it invaluable during labor and delivery, as well as post-operative care in the ICU.
Recommendations
For optimal results, regular calibration and maintenance of the monitor are recommended. Familiarize the medical staff with its functionalities to utilize all features fully. Consider optional upgrades to enhance its capabilities further.
Features
- 17-inch LCD screen for clear visibility
- Standard parameters include ECG, SPO2, TEMP, NIBP, RESP, and PR/HR
- Optional modular upgrades available
Technical Specifications
| Model | YR02180 | |
|
ECG
|
Lead mode | 5 Leads(RA,LA,LL,RL,V) |
| Connection method | I, II, III,AVR,AVL,AVF,V | |
| Lead Mode | 3 Leads (RA,LA,LL) | |
| Connection method | I, II,III | |
| Gain | x250, x500, x1000, x2000 | |
| Accuracy | ±5% | |
| Resolution | 1bpm | |
| Sensitivity | >200(uVp-p) | |
| Differential input impedance | ≥5MΩ | |
| ST segment Monitoring Range | ||
| Measure Range | -1.0~+1.0mV | |
| Measure Accuracy | -0.8mV~+0.8mV | |
|
Heart Rate
|
Measuring range | 40~240bpm |
| Accuracy | ±3bpm | |
| Resolution | 1bpm | |
| Sensitivity | >200UVp-p | |
|
Respiration
|
Method | Impedance between R-F(RA-LL) |
| Measuring Impedance Range | 0.3~3.0 MΩ | |
| Bandwidth | 0.1~2.5Hz | |
| Respiration Rate | Adult: 7~120BrPM | |
| Neo/Ped | 7~150BrPM | |
| Resolution | 1 BrPM | |
| Accuracy | ±2 BrPM | |
|
NIBP
|
Method | Oscillometric |
| Measuring Interval in AUTO Mode | 1,2,3,4,5,10,15,30,60,90,120,180,240(Min) | |
| Measuring Period in STAT Mode | 5 Min | |
| Pulse Rate Range | 40~240bpm / 40~150bpm | |
| Alarm Type | SYS, DIA, MEAN | |
| Resolution | ||
| Pressure | 1mmHg | |
|
SPO2
|
Display | Number of SPO2,waveform of capacity,Pulse |
| Measuring range | 0~100% | |
| Resolution | 1% | |
| Accuracy | 70~99% (±2%) | |
| Pulse rate range | 0~300bpm | |
|
TEMP
|
Channel | 2 |
| Measuring and Alarm Range | 0~50ºC | |
| Resolution | 0.1ºC | |
| Accuracy | 0.1ºC | |
| Actualization interval | about 1 Second. | |
| Average Time Constant | <10 Second. | |
