Description
The Biological Microscope YR0242-M // YR0242-T offers precision and versatility for both educational and professional use. With options for monocular, binocular, and trinocular heads, this microscope caters to different observational needs. It features a quadruple nosepiece with a precise click-stop mechanism and a high-quality Abbe condenser with brightness-adjustable LED lighting. Additionally, the infinity plan and achromatic optical systems ensure sharp and clear imaging, making it an excellent choice for detailed biological studies.
Market Price Overview
The Biological Microscope YR0242-M // YR0242-T typically falls within a price range of 400 USD to 1300 USD in the market. This range reflects the advanced optical and functional capabilities it offers compared to other models of similar caliber. Investing in this device ensures you receive high precision and diverse configurations to suit various research needs.
Frequently Asked Questions
Q: Can this microscope be used for advanced biological studies?
A: Absolutely, the YR0242 series is equipped with high-quality optics and configurations suitable for detailed research and educational purposes.
Q: Is there a warranty included with the microscope?
A: Yes, all purchases include a manufacturer’s warranty ensuring quality and durability.
Advantages and Disadvantages
One of the key advantages of the Biological Microscope YR0242-M // YR0242-T is its versatility in head configuration, which accommodates various observational styles. The superior optical systems provide excellent image clarity. However, a potential downside is that its advanced features require a learning curve for optimal use.
Product Use in the Field
This microscope is ideal for use in educational settings and research labs, providing reliable performance for biological specimen analysis. Its adjustable lighting and head rotation features make it suitable for prolonged observation and detailed study, thus maximizing user comfort and efficiency.
Recommendations
For optimal performance, regularly clean the optical components and ensure proper calibration of all adjustable features. Using the microscope in a well-lit environment and at recommended settings can help maintain image quality and device longevity.
Features
- Configurable head options: monocular, binocular, trinocular
- Quadruple nosepiece with precise click-stop
- High brightness LED with adjustable intensity
- Infinity plan and achromatic optical systems
- Integrated double-layer mechanical stage
Technical Specifications
| Model No. | YR0242-M | YR0242-B | YR0242-T |
| Video Adapter | —— | C-Mount 0.3x | —— |
| Power Supply Type | AC 110V-240V | —— | |
| Transmit Light | Halogen 6V20W or LED Optional | ||
| Light Source Type | Halogen | ||
| Condenser N.A. | 1.25 | ||
| Condenser Type | Abbe | ||
| Condenser Features | Rack & Pinionↆ↑, Filter Holder, Center Adjustable | ||
| Focusing Scale | 0.002mm | ||
| Focusing Range | 36mm | ||
| Focusing Type | Coaxial Coarse & Fine | —— | |
| Focusing Features | Safety Stop Screw Tension Adjustable | ||
| Working Stage Moving | 75*50mm | ||
| Working Stage Size | 132*142mm | ||
| Working Stage Type | 2 Layers Mechanical | ||
| Objective | Achromatic 4x, 10x, 40x(S), 100x(O,S) | ||
| Objective Type | Achromatic | ||
| Nosepiece Holes | 4 Holes | ||
| Nosepiece Features | Inward | ||
| Eyepiece | WF10x/18mm | ||
| Eyepiece Diameter | 23.2mm | ||
| Head Interpupillary | 54~75mm | ||
| Head Rotation | Head Rotate 360° | —— | |
| Head Inclination | 30° | —— | |
| Head Type | Monocular | Binocular | Seidentopf Trinocular |
| Standard Magnification | 40x-1000x | —— | |
| Optical System | Achromatic | ||
| Standard Function | BF | —— | |
