Description
Benchtop Spectrophotometer YR05477 is an advanced bench-top measurement instrument developed independently by Kalstein to evaluate both the color and appearance of objects for reflectance measurements and the transmittance of translucent or transparent liquids and solids. Compact yet feature-rich, it boasts a 7-inch TFT capacitive touch screen and supports full illuminants, reflective d/8 and transmissive d/0 geometry, including or excluding UV options. Its precision, stability, and comprehensive data storage capacity make it an essential tool for color analysis within research and development environments, as well as laboratories.
Market Price
The Benchtop Spectrophotometer YR05477 offers exceptional value for its features and technical specifications. Spectrophotometers in this category generally fall within a price range of approximately $10,000 to $11,000 USD. Prices can vary based on supplier promotions and additional features or accessories included in the purchase. It’s essential to consider this range when planning your budget for purchasing this crucial laboratory equipment.
Frequently Asked Questions
Q: What industries can benefit from using the Benchtop Spectrophotometer YR05477?
A: This spectrophotometer is versatile and can be used across multiple industries, including plastics, electronics, paint and ink, printing, garments, leather, paper, cosmetics, food, and more. It’s particularly beneficial for color transfer and quality control applications.
Q: How easy is it to operate this spectrophotometer?
A: The YR05477 is designed with user-friendliness in mind. Its 7-inch TFT touch screen provides an intuitive interface, allowing for straightforward operation and data analysis.
Advantages and Disadvantages
Advantages: The YR05477 boasts high accuracy and stable color measurements, a large data storage capacity, multiple measurement modes, and a wide range of apertures that can be customized to fit specific needs.
Disadvantages: The complexity of its features might require some initial training or familiarity with laboratory instruments for optimal use.
Product Use in the Field
The Benchtop Spectrophotometer YR05477 is widely employed in laboratory settings for rigorous color and quality analysis. It is frequently used in R&D environments for developing new products and ensuring the consistency of colors across materials. Industries such as textiles, paints, and food production rely on this precision instrument to maintain stringent quality standards.
Recommendations
To maximize the life and performance of your Benchtop Spectrophotometer YR05477, ensure it is calibrated regularly and stored under the recommended environmental conditions. Make use of the Kalstein Plus platform to request a custom quote and explore the full suite of accessories and features that can enhance its utility further.
Features
- 7 inches TFT Color Capacitive Touch-screen Display
- Double Array 256 Image Element CMOS Sensor
- Wide wavelength range from 360nm to 780nm
- Multiple measurement modes and customizable measuring apertures
- Built-in temperature sensor for precision measurements
Technical Specifications
| Model | YR05477 |
| Optical Geometry | Reflect: di:8°, de:8°(diffused illumination, 8-degree viewing angle); SCI/SCE; Include UV/excluded UV light source. Transmittance: di:0°, de:0° (diffuse illumination: 0° viewing); SCI/SCE; Include UV/excluded UV light source; Haze(ASTM D1003). |
| Application | It is used for accurate analysis and transmission of laboratory color. Apply in paints, inks, textiles, garments, printing and dyeing, printing etc industries for color transfer and quality control. |
| Integrating Sphere Size | Φ154mm |
| Light Source | 360 nm to 780 nm, Combined LED Light, 400nm cut-off light source |
| Spectrophotometric Mode | Concave Grating |
| Sensor | 256 Image Element Double Array CMOS Image Sensor |
| Wavelength Range | 360-780nm |
| Wavelength Interval | 10nm |
| Semiband Width | 10nm |
| Measured Reflectance Range | 0-200% |
| Measuring Aperture | Reflective: Φ30mm/Φ25.4mm, Φ10mm/Φ8mm, Φ6mm/Φ4mm; |
| Transmissive: Φ30mm/Φ25mm; | |
| Remark: 1. Automatic identification of switch caliber 2. Customized Configuration caliber and lens position | |
| Specular Component | Reflectance: SCI&SCE / Transmittance: SCI&SCE |
| Color Space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,Musell,s-RGB,HunterLab,βxy,DIN Lab99 |
| Color Difference Formula | ΔE * ab ,ΔE * uv ,ΔE * 94 ,ΔE * cmc(2:1) ,ΔE * cmc(1:1) ,ΔE * 00 , DINΔE 99 ,ΔE (Hunter), |
| Other Colorimetric Index | WI (ASTM E313, CIE/ISO, AATCC, Hunter), |
| YI (ASTM D1925, ASTM 313), | |
| MI (Metamerism Index), | |
| Staining Fastness, Color Fastness, Color Strength, Opacity, | |
| 8° Glossiness,Gardner Index, Pt-Co Index, 555 Index, Haze(ASTM D1003) | |
| Observer Angle | 2°/10° |
| Illuminant | D65,A,C,D50,D55,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12 |
| Displayed Data | Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset |
| Measuring Time | About 2.4s (Measure SCI & SCE about 5s) |
| Repeatability | Spectral reflectance: Φ25.4mm/SCI, Standard deviation within 0.05% (400 nm to 700 nm: within 0.04%) |
| Chromaticity value:Φ25.4mm/SCI, Standard deviation within ΔE*ab 0.02 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration) Spectral Transmittance: Φ25.4mm/SCI, Standard deviation within 0.05% (400 nm to 700 nm: within 0.04%) | |
| Chromaticity value:Φ25.4mm/SCI, Standard deviation within ΔE*ab 0.03 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration) | |
| Inter-instrument Error | Φ25.4mm/SCI, Within ΔE*ab 0.15 |
| (Average for 12 BCRA Series II color tiles) | |
| Dimension | L*W*H=370x300x200mm |
| Weight | Approx. 9.6kg |
| Power | AC 24V, 3A Power adapter power supply |
| Illuminant Life Span | 5 years, more than 3 million times measurements |
| Display | 7-inch TFT color LCD, Capacitive Touch Screen |
| Data Port | USB & Print serial port |
| Data Storage | Standard 2000 Pcs, Sample 20000 Pcs |
| Language | Simplified Chinese, Traditional Chinese, English, |
| Operating Environment | 0~40℃, 0~85%RH (no condensing), Altitude < 2000m |
| Storage Environment | -20~50℃, 0~85%RH (no condensing) |
| Standard Accessory | Power Adapter, User Guide, CD Disk(PC Software), USB cable, Standard Calibration Board, Black Calibration Cavity, Transmission black baffle, Sample holder, 25.4 caliber, 8 caliber, 4 caliber |
| Optional Accessory | Micro-printer, Transmissive Test Component, Micro Aperture(4mm) transmission test clamp component, Instrument inversion components |
| Notes: The specifications are subject to change without notice. | |
