Description
The 328 Liters Medical Deep Freezer For Laboratory YR05294 is an ideal solution for storing vaccines, blood plasma, and various biological materials. Equipped with a chemically stable, CFC-free refrigerant, this freezer is not only environmentally safe but also highly efficient. With a microprocessor control and an adjustable temperature range from -10℃ to -25℃, it provides optimal storage conditions for sensitive materials. Its LED digital display ensures precise monitoring, while the robust insulation maintains a stable temperature essential for laboratory and clinical use.
Market Price
With increasing demand in medical and research fields, the price of medical deep freezers varies significantly. A good quality model like the YR05294 generally falls within the $2300 to $3100 range, depending on features and manufacturer. The investment in a top-tier freezer ensures the safest preservation of critical biological samples.
Frequently Asked Questions
- What is the warranty period for this medical freezer? Typically, these freezers come with a standard one-year warranty, but it’s always best to confirm with the supplier.
- Is the temperature range customizable? Yes, the freezer allows for temperature adjustments between -10℃ and -25℃.
- Can the freezer be moved easily? Yes, the freezer features lockable casters that enable mobility as needed.
Advantages and Disadvantages
- Advantages: Wide temperature range, environmentally friendly refrigerant, energy-efficient operation, robust insulation, and comprehensive safety alarms.
- Disadvantages: Manual defrosting is required and initial cost can be high compared to conventional freezers.
Field Use
The freezer excels in scenarios where maintaining precise temperature control is critical, such as in hospitals, laboratory research settings, and pharmaceutical environments. It’s engineered to ensure safe storage of sensitive materials, which is crucial for maintaining the integrity of samples and products.
Recommendations
To maximize the longevity and performance of the freezer, regular maintenance checks are recommended. Ensure proper ventilation by placing the freezer in an area with sufficient airflow. Additionally, calibrate the temperature settings periodically to align with the specific storage needs of your materials.
Features
- CFC-free, safe refrigerant
- High density foam insulation
- LED Digital Display
- Wide voltage tolerance (187~242 V/AC)
- Multiple malfunction alarms
- Audible and visual alarm systems
- Secure door lock
Technical Specifications
Model | YR05294 |
Performance | |
Temperature Range | -10℃~-25°C |
Ambient Temperature | +10~+32°C |
Controller | Microprocessor |
Display | Digital Display |
Refrigeration System | |
CompressorBrand | 1/CUBIGEL |
Refrigerant | R290 |
Cooling Type | Direct cooling |
Defrost Type | Manual |
Dimensions | |
Capacity | 328L |
Interior Size(W*D*H) | 508*455*1393mm |
Exterior Size(W*D*H) | 690*680*1900mm |
Package Size(W*D*H) | 750*760*2030mm |
N.t./G.t.(approx) | 104/125kg |
Loading Qty(20’/40’/40’H) | 21/48/48 |
Electrical Data | |
Power Supply(V/Hz) | 220~240V/50~60;115/60 |
Rated Power(W) | 180 |
Electrical Current(A) | 1.4 |
Power Consumption | 3 kWh/24h |
Power failure alarm | 8H |
